    Capacity:5.2KW

    WindFree™ 4-Way Cassette High Efficiency

    AC052BN4PKGEU

    Find an installer

    Product Specifications

    • Features

      Features

      • Type

        EU-5.2kW-4way-1

    • Model Name

      Model Name

      • Indoor Unit

        AC052BN4PKG/EU

      • Outdoor Unit

        AC052BXAPKG/EU

    • System

      System

      • Mode

        Heat Pump

    • Capacity

      Capacity

      • Cooling [kW]

        1.10 / 5.00 / 8.00 kW

      • Heating [kW]

        1.10 / 6.00 / 9.50 kW

    • Power Input

      Power Input

      • Cooling 1)

        0.24 / 1.16 / 2.90 kW

      • Heating 2)

        0.22 / 1.37 / 3.15 kW

    • Current Input

      Current Input

      • Cooling (℃)

        1.6 / 5.5 / 12.7 A

      • Heating (℃)

        1.5 / 6.3 / 14.0 A

    • Power

      Power

      • MCA

        17.5 A

      • MFA

        20.0 A

    • Energy Efficiency

      Energy Efficiency

      • Energy Grade (Cooling)

        SEER 8.5 (A+++)

      • Energy Grade (Heating)

        SCOP 4.9 (A++)

    • Piping Connections

      Piping Connections

      • Liquid Pipe (Ø, mm)

        6.35 mm

      • Gas Pipe (Ø, mm)

        12.7 mm

      • Installation Max. Length [m]

        50 m

      • Installation Max. Height [m]

        30 m

    • Field Wiring

      Field Wiring

      • Transmission Cable

        0.75 ㎟ ↑

    • Refrigerant

      Refrigerant

      • Type

        R32(Contains fluorinated greenhouse gases, GWP=675)

      • Factory Charging (kg)

        1.70 kg

      • Factory Charging (tCO2e)

        1.15 tCO2e

      • Control Method

        EEV

    • Power Supply (Indoor Unit) [Φ, #, V, Hz]

      Power Supply (Indoor Unit) [Φ, #, V, Hz]

      • 1, 2, 220-240, 50

    • Fan

      Fan

      • Type

        Turbo

      • Air Flow Rate (High / Mid / Low) [m3/min]

        (C)13.5/12.7/11.8 (H)14.3/13.5/12.7 CMM

      • Motor (Output) [W]

        65 W

      • Number of Unit (EA)

        1 EA

    • Drain

      Drain

      • Drain Pipe (Ø,mm)

        VP25 (OD 32 / ID 25) mm

    • Sound

      Sound

      • Sound Pressure Level (High / Mid / Low) [dB(A)]

        33 / 31 / 29 dBA

      • Sound Power Level (Cooling) [dB(A)]

        49 dBA

    • External Dimension (Indoor Unit)

      External Dimension (Indoor Unit)

      • Net Weight (kg)

        16.0 kg

      • Net Dimensions (WxHxD) (mm)

        840 x 204 x 840 mm

    • Panel

      Panel

      • Model Name

        PC4NUFMAN

      • Net Weight (kg)

        6.3 kg

      • Shipping Weight (kg)

        8.7 kg

      • Net Dimensions (WxHxD) (mm)

        950 x 48 x 950 mm

      • Shipping Dimensions (WxHxD) (mm)

        1,010 x 117 x 1,000 mm

    • Additional Accessories

      Additional Accessories

      • Drain Pump

        DC (Include)

      • Drain Pump Max. Lifting Height/Displacement

        750 / 24

    • Power Supply (Outdoor Unit) [Φ, #, V, Hz]

      Power Supply (Outdoor Unit) [Φ, #, V, Hz]

      • 1, 2, 220-240, 50

    • Fan (Outdoor Unit)

      Fan (Outdoor Unit)

      • Air Flow Rate (Cooling) [m3/min]

        55 CMM

    • Sound (Outdoor Unit)

      Sound (Outdoor Unit)

      • Sound Pressure (Cooling / Heating) [dB(A)]

        47 / 48 dBA

      • Sound Power Level (Cooling) [dB(A)]

        63 dBA

    • External Dimension (Outdoor Unit)

      External Dimension (Outdoor Unit)

      • Net Weight (kg)

        50.0 kg

      • Net Dimensions (WxHxD) (mm)

        880 x 798 x 310 mm

    • Operating Temp. Range

      Operating Temp. Range

      • Cooling (°C)

        -20~52 ℃

      • Heating (°C)

        -25~24 ℃

    • Smart

      Smart

      • WiFi Kit

        Yes

    • App Connectivity

      App Connectivity

      • SmartThings App Support

        Yes


    Download the product information sheet for more technical data
