Product Specifications
Features
Features
features
Type
1Way CASSETTE
Model Name
Model Name
model_name
Indoor Unit
AM017NN1PEH/EU
Power Supply (Indoor Unit) [Φ, #, V, Hz]
Power Supply (Indoor Unit) [Φ, #, V, Hz]
power_supply_indoor_unit___v_hz
1,2,220-240,50
System
System
system
Mode
HP/HR
Capacity
Capacity
capacity
Cooling [kW]
1.7 kW
Heating [kW]
1.9 kW
Power Input
Power Input
power_input
Cooling [kW]
0.024 kW
Heating [kW]
0.024 kW
Current Input
Current Input
current_input
Cooling (℃)
0.14 A
Heating (℃)
0.14 A
Fan
Fan
fan
Type
Crossflow Fan
Air Flow Rate (High / Mid / Low) [l/s]
80.00/71.67/68.33
Motor (Output) [W]
27 x 1 W
Air Flow Rate (High / Mid / Low) [m3/h]
288/258/246 ㎥/h
Piping Connections
Piping Connections
piping_connections
Liquid Pipe (Ø, mm)
6.35 mm
Liquid Pipe (Ø, inch)
1/4"
Gas Pipe (Ø, mm)
12.70 mm
Gas Pipe (Ø, inch)
1/2"
Drain Pipe (Ø,mm)
VP20 (OD 25,ID 20) mm
Refrigerant
Refrigerant
refrigerant
Type
R410A(Contains fluorinated greenhouse gas, GWP=2,088)
Control Method
EEV INCLUDED
Sound
Sound
sound
Sound Pressure Level (High / Mid / Low) [dB(A)]
28 / 26 / 24 dBA
Sound Power Level
46.0 dBA
External Dimension (Indoor Unit)
External Dimension (Indoor Unit)
external_dimension_indoor_unit
Net Weight (kg)
8.0 kg
Net Dimensions (WxHxD) (mm)
740 x 135 x 360 mm
Panel
Panel
panel
Model Name
PC1MWFMAN
Net Weight (kg)
2.6 kg
Shipping Weight (kg)
3.8 kg
Net Dimensions (WxHxD) (mm)
960 x 35 x 420 mm
Shipping Dimensions (WxHxD) (mm)
1003 x 112 x 482 mm
Field Wiring
Field Wiring
field_wiring
Power Source Wire
1.5 ~ 2.5
Transmission Cable
0.75 ~ 1.50
Download the product information sheet for more technical data
