Capacity:5.2KW
Climate comfort with a clean design
Discover our versatile Duct line-up, designed to meet your every need. Effortlessly adaptable, our Duct units deliver seamless performance with a clean design.
.jpg/_jcr_content/renditions/image-introduction.png)
Features
Smart Control
Control the temperature at home, anytime and anywhere. The SmartThings App¹ enables users to remotely control their air conditioner. With just the touch of a button, you can turn the air conditioner on or off, select the cooling mode, schedule the air conditioner’s operation and monitor its power consumption. With the Bixby 2.0 Samsung’s voice interface assistant², you can simply tell the device what they want, and the device carries out their wishes³. It even analyses the environment, preferred mode and temperature and suggests the best settings for inside the home.
SolarCell Remote Controller (Optional)
Samsung introduces the SolarCell Remote controller to its air conditioning line-up as an option. The new SolarCell remote controller focuses on innovative charging, slim design and easy usability features. The SolarCell remote controller does not need batteries; instead a solar panel is integrated on the back of the remote controller that allows charging by exposing it under direct light. A single, fully charged battery can last up to two years, making it an economical alternative to disposable batteries. In addition, there is also a USB-C port on the bottom of the remote control for fast charging. It has better grip, easier button controls, large OLED display and it is lightweight⁴.
Product Specifications
Features
Features
features
Type
MA duct
Model Name
Model Name
model_name
Indoor Unit
AJ052BNMDEG/EU
Power Supply (Indoor Unit) [Φ, #, V, Hz]
Power Supply (Indoor Unit) [Φ, #, V, Hz]
power_supply_indoor_unit___v_hz
1,2,220-240,50
System
System
system
Mode
HP
Capacity
Capacity
capacity
Cooling [kW]
5.2 kW
Heating [kW]
5.6 kW
Power Input
Power Input
power_input
Cooling [W]
50 W
Heating [W]
50 W
Current Input
Current Input
current_input
Cooling (℃)
0.45 A
Heating (℃)
0.45 A
Fan
Fan
fan
Type
Sirroco Fan / BLDC
Motor (Output) [W]
84 x 1 W
Air Flow Rate (High / Mid / Low) [m3/min]
14.0 / 9.8 / 5.4 CMM
Air Flow Rate (High / Mid / Low) [l/s]
233 / 163 / 90
External Static Pressure (Min / Std / Max) [mmAq]
0 / 2 / 5.1 mmAq
External Static Pressure (Min / Std / Max) [Pa]
0 / 19.6 / 50.0 Pa
Piping Connections
Piping Connections
piping_connections
Liquid Pipe (Ø, mm)
6.35 mm
Liquid Pipe (Ø, inch)
1/4
Gas Pipe (Ø, mm)
12.7 mm
Gas Pipe (Ø, inch)
1/2
Drain Pipe (Ø,mm)
VP25 (OD 32, ID 25) mm
Field Wiring
Field Wiring
field_wiring
Power Source Wire
1.5 ~2.5
Transmission Cable
0.75 ~ 1.5
Refrigerant
Refrigerant
refrigerant
Type
R32(Contains fluorinated greenhouse gases, GWP=675)
Control Method
EEV NOT INCLUDED
Sound
Sound
sound
Sound Pressure
33 / 29 / 23 dBA
Sound Power Level
53 dBA
External Dimension (Indoor Unit)
External Dimension (Indoor Unit)
external_dimension_indoor_unit
Net Weight (kg)
18.9 kg
Net Dimensions (WxHxD) (mm)
900 x 199 x 440 mm
Smart
Smart
smart
WiFi Kit
N/A
App Connectivity
App Connectivity
app_connectivity
SmartThings App Support
N/A
Disclaimers:
1. A Wi-Fi connection with a Wifi Kit (MIM-H04EN) and Samsung's SmartThings application account are required. Requires iOS 10.0 or later & Android 5.0 or later.
2. Bixby is Samsung’s voice interface assistant. The voice control is supported by Samsung Bixby 2.0 and Google Assistant (Google Home). Google Assistant is not available in certain languages and countries. Google is a trademark of Google LLC.
3. Currently Voice control is supported in English (US, UK, Indian), Chinese, Korean, French, German, Italian, Spanish and Portuguese.
4. Compared to the conventional infrared remote controller for example, the AR-EH03.
