Custom operation at any time
You can set the priorities and the operating modes for the TDM Plus heat pump using the control unit. You can also adapt the settings or parameters that suit you.
Product Specifications
Features
Features
features
Type
EHS TDM PLUS
Mode
Heat Pump (A2W)
Current Input
Current Input
current_input
Cooling (℃)
8.50 A
Heating (℃)
9.60 A
Energy Efficiency
Energy Efficiency
energy_efficiency
EER (Cooling) [W/W]
4.32
COP (Heating) [W/W]
4.25
Capacity
Capacity
capacity
Cooling [kW]
8.00 kW
Heating [kW]
9.00 kW
Power
Power
power
MCA
22.00 A
MFA
27.50 A
Power Input
Power Input
power_input
Cooling 1)
1.85 kW
Heating 2)
2.12 kW
Fan
Fan
fan
Type
Propeller Fan
Air Flow Rate (High / Mid / Low) [m3/min]
67 CMM
Piping Connections
Piping Connections
piping_connections
Liquid Pipe (Ø, mm)
9.52 mm
Liquid Pipe (Ø, inch)
3/8
Gas Pipe (Ø, mm)
15.88 mm
Gas Pipe (Ø, inch)
5/8
Refrigerant
Refrigerant
refrigerant
Type
R410A(Fluorinated greenhouse gas, GWP=2,088)
Factory Charging (kg)
2.4 kg
Factory Charging (tCO2e)
5.01 tCO2e
Sound
Sound
sound
Sound Pressure
C: 50 / H: 51 dBA
Sound Power Level
69 dBA
Operating Temp. Range
Operating Temp. Range
operating_temp_range
A2W Heating (°C)
-25~35 °C
A2W Cooling (°C)
10~46 °C
Domestic Hot Water (°C)
-25~43 °C
A2A Heating (°C)
-25~24 °C
A2A Cooling (°C)
10~46 °C
External Dimension (Outdoor Unit)
External Dimension (Outdoor Unit)
external_dimension_outdoor_unit
Net Weight (kg)
74.0 kg
Net Dimensions (WxHxD) (mm)
940 x 998 x 330 mm
