HVM Chiller: a modular and flexible solution

Scroll down

P198 199 TIME4537 1 dr02bwP198 199 TIME4537 1 dr02bw

An HVM Chiller system combines the benefits of VRF and Chiller technologies. This solution is suitable for retrofit and new design projects. The outdoor units are available in three different sizes: 42/56/65 kW. A maximum of 16 outdoor units can be connected to achieve a maximum capacity of 1,040 kW.

Samsung HVM systems

A Samsung VRF Chiller air conditioning system follows a modular concept with the option of combining up to 16 HVM outdoor units to form one climate solution. The system can be connected to a wide range of indoor fan coil units such as the 360 Cassette or One-Way Cassette. Water is used to comfortably cool and heat any type of space. An HVM system can also be connected to thermal storage systems and hot water systems.

Samsung Schematics VRF Chiller LowBuilding

Key features of HVM Chiller systems

Optimised for energy efficiency

HVM Chillers are optimised for energy efficiency². They have high-performance compressors, advanced control systems, and other energy-reducing technologies. When multiple HVM Chiller units are connected within a single system, the workload is automatically adjusted for maximum efficiency³. This means, for instance, that at low load, the outdoor units are switched on at alternate intervals.

The HVM Selection tool

The intuitive Samsung HVM online selection tool enables you to streamline the chiller system design process. In short, it simplifies the process of designing a complete chiller system in a modular way. The tool provides essential information including efficiency data, total water flow, and total system pressure drop, which helps you to easily select the appropriate water pump and piping.

dk installer installer imagery formal shoot boardroom CROPPED

Become an installer

Join our network of qualified and experienced installers that offer expert services in the installation and maintenance of our climate control systems.

Join us

DK commercial 360 cassette

Discover other commercial air conditioning solutions

Samsung offers commercial climate solutions for every customer and every space. Explore all our options.  Samsung offers commercial climate solutions across a diverse customer, space and requirement need.

Discover more

Disclaimers:

1. The refrigerant charge of a HVM Chiller is up to 65 % lower than in traditional VRF systems. Compared to a Samsung DVM S 60 HP, holding R410A refrigerant, connected to twelve 14 kW indoor units and 100 meters of pipes.

2. HVM Chiller outdoor units have a SEER (Nominal Cooling) of 5.7 and SCOP (Nominal Heating) of 4.3. Tested based on the AG042 model at test conditions: Water 35 degrees celsius without pump input. Results may vary depending on environmental factors and individual use.

3. At low load, the varying outdoor units are switched on at alternate intervals. At average load, the outdoor units are operated at partial load to optimise efficiency. At maximum load, all compressors of all outdoors unit are operated at maximum capacity.
