Capacity:8.0kW
Product Specifications
Features
Features
features
Type
Outdoor DVM
Model Name
Model Name
model_name
Outdoor Unit
AM080HCMDNG/EU
Power Supply (Outdoor Unit) [Φ, #, V, Hz]
Power Supply (Outdoor Unit) [Φ, #, V, Hz]
power_supply_outdoor_unit___v_hz
3, 4, 380 ~ 415, 50 / 60
System
System
system
Mode
Heat Pump
Capacity
Capacity
capacity
HP
8.00 HP
Capacity (Rated)
Capacity (Rated)
capacity_rated
Cooling [kW]
22.40 kW
Heating [kW]
22.40 kW
Power Input (Rated)
Power Input (Rated)
power_input_rated
Cooling (℃)
7.86 kW
Heating (℃)
5.21 kW
Current Input (Rated)
Current Input (Rated)
current_input_rated
Cooling (℃)
12.20 A
Heating (℃)
8.10 A
Power
Power
power
MCA
18.0 A
MFA
25.0 A
Energy Efficiency (Rated)
Energy Efficiency (Rated)
energy_efficiency_rated
EER (Rated Cooling)
2.85 W/W
COP (Rated Heating)
4.30 W/W
Heat Exchanger (Outdoor Unit)
Heat Exchanger (Outdoor Unit)
heat_exchanger_outdoor_unit
Type
Fin & Tube
Material (Fin)
Albania
Material (Tube)
Cu
Fin Treatment
Anti-corrosion
Compressor
Compressor
compressor
Type
Scroll Inverter
Output (kW)
4.91 kW
Model Name
DS2BD7046FVA
Oil (Type)
POE
Oil (Initial Charge) [cc]
900 cc
Fan
Fan
fan
Type
Propeller
Air Flow Rate [m3/min]
135 ㎥/min
Air Flow Rate [l/s]
2250 l/s
External Static Pressure [mmAq]
3.0 mmAq
External Static Pressure [Pa]
29.4 Pa
Fan Motor
Fan Motor
fan_motor
Output (W)
139 W
Quantity (EA)
2 EA
Piping Connections
Piping Connections
piping_connections
Liquid Pipe Type
Braze Connection
Liquid Pipe Diameter (mm)
9.52 mm
Liquid Pipe Diameter (inch)
3/8 inch
Gas Pipe Type
Braze Connection
Gas Pipe Diameter (mm)
19.05 mm
Gas Pipe Diameter (inch)
3/4 inch
Discharge Gas Pipe Type
Braze Connection
Installation Max. Length [m]
100 m
Installation Max. Height [m]
30 m
Refrigerant
Refrigerant
refrigerant
Type
R32
Factory Charging (kg)
3.00 kg
Factory Charging (tCO2e)
2.03 tCO2e
Sound
Sound
sound
Sound Pressure Level (Mid)
58 dB(A)
Sound Power Level
73 dB(A)
External Dimension (Outdoor Unit)
External Dimension (Outdoor Unit)
external_dimension_outdoor_unit
Net Weight (kg)
120 kg
Shipping Weight (kg)
133 kg
Net Dimensions (WxHxD) (mm)
940 x 1,420 x 330 mm
Shipping Dimensions (WxHxD) (mm)
995 x 1,598 x 426 mm
Operating Temperature Range
Operating Temperature Range
operating_temperature_range
Cooling (Min) (°C)
-5.0 ℃
Cooling (Max) (°C)
52.0 ℃
Heating (Min) (°C)
-25.0 ℃
Heating (Max) (°C)
24.0 ℃
Field Wiring
Field Wiring
field_wiring
Transmission Cable
0.75
