Get to know the future of heating and cooling
The DVM S Mini R32 features a small footprint and is light weight. At the same time, it’s a powerful heating and cooling system that includes Silent Mode³, sound absorbing technology to reduce noise distractions. Combined with specially shaped fans and compact, unimposing design it creates a more pleasant residential and working environment. Additionally, its quiet operation at night creates a restful environment with a reduced noise level of 3–7 dB(A)⁴.
Unmatched comfort with a wide temperature range
The DVM S R32 Mini sets a new standard in heating and cooling versatility. Designed to operate efficiently in a broad range of temperatures, this unit ensures optimal performance in both residential and light commercial environments. With a cooling operation range from -5°C to 48°C and heating operation range from -25°C to 26°C, the DVM S R32 Mini maintains comfort even in extreme conditions⁷.
1. GWP R32: 675 GWP R410A: 2088 R32 refrigerant charge 2.2kg tCO2e=1.49 R410A refrigerant charge 2.00 & 2.5 kg tCO2e=4.18 & 5.22 Reference: TDB
2. Only available on certain models
3. Silent mode can be activated by the installer depending on the model code during the installation/service stage.
4. Based on internal testing comparing silent mode with regular operating mode. The sound pressure level is obtained in an anechoic room. Sound pressure level is a relative value, depending on the distance and acoustic environment. Sound pressure levels may differ depending on operation conditions. Silent mode is available by option setting. Based on internal testing. Results may vary depending on environmental factors and individual use.
5. Based on internal testing of the cooling operation, with the temperature set at 22°C and using Auto mode for 4 hours, at a room temperature of 33°C and an external temperature of 35°C. The tested model was an AM06EU0DXMDKG/EU connected to AM140DN4DKG/EU indoor unit with 25m of piping. The elapsed times were measured when the room temperature reached 25°C.
6. Samsung SmartThings application account and internet connection are required. Requires iOS 10.0 or later & Android 5.0 or later
7. If the indoor temperature is between 10°C and 15°C, warming up mode must be completed before it can work in heating mode’ to make it easier to understand and have a positive twist to it.
Product Specifications
Features
Features
features
Type
DVM S Eco
Model Name
Model Name
model_name
Outdoor Unit
AM040DXMDKG/EU
Power Supply (Outdoor Unit) [Φ, #, V, Hz]
Power Supply (Outdoor Unit) [Φ, #, V, Hz]
power_supply_outdoor_unit___v_hz
1,2,220~240,50/60
System
System
system
Mode
HEAT PUMP
Performance (nominal)
Performance (nominal)
performance_nominal
4 HP
Capacity
Capacity
capacity
Cooling [kW]
- kW
Heating [kW]
- kW
Capacity (Rated)
Capacity (Rated)
capacity_rated
Cooling [kW]
12.10 kW
Heating [kW]
12.10 kW
Heating (Max)
14.20 kW
Connectable Indoor Units
Connectable Indoor Units
connectable_indoor_units
Maximum Number of Connectable Indoor Units
8 EA
Total Capacity of the Connected Indoor Units Min. [kW]
6.00 kW
Total Capacity of the Connected Indoor Units Max. [kW]
15.70 kW
Power Input
Power Input
power_input
Cooling [kW]
3.73 kW
Heating [kW]
2.75 kW
Current Input
Current Input
current_input
Cooling (℃)
17.1 A
Heating (℃)
12.6 A
Power
Power
power
MCA
22.0 A
MFA
25 A
Minimum Ssc
Equipment complying withIEC61000-3-12 MVA
Energy Efficiency
Energy Efficiency
energy_efficiency
EER (Cooling) [W/W]
3.24 W/W
COP (Heating) [W/W]
4.40 W/W
SEER (Ducted)
7.90 W/W
SCOP (Ducted)
4.80 W/W
ŋs.c (Ducted)
313.00 %
ŋs.h (Ducted)
189.00 %
SEER (Non-Ducted)
8.50 W/W
SCOP (Non-Ducted)
5.10 W/W
ŋs.c (Non-Ducted)
337.00 %
ŋs.h (Non-Ducted)
201.00 %
Pdesignh
8.20 kW
Casing
Casing
casing
Material (Body)
GI Steel Plate
Material (Base)
GI Steel Plate
Heat Exchanger
Heat Exchanger
heat_exchanger
Type
Fin & Tube
Material (Fin)
Albania
Material (Tube)
Cu
Fin Treatment
Anti-corrosion
Compressor
Compressor
compressor
Type
Twin BLDC Rotary
Output (kW x n)
4.35 kW
Model Name
UB5TD8450FJX
Oil (Type)
POE
Oil (Initial Charge) [cc x n]
1500 cc
Fan
Fan
fan
Type
Propeller
Discharge Direction
Side
Quantity
1 EA
Air Flow Rate [m3/min]
69.00 ㎥/min
Air Flow Rate [l/s]
1150 l/s
External Static Pressure [mmAq]
- mmAq
External Static Pressure [Pa]
- Pa
Fan Motor
Fan Motor
fan_motor
Type
BLDC Motor
Output (W x n)
122 x 1 W
Piping Connections
Piping Connections
piping_connections
Liquid Pipe Type
Braze Connection
Liquid Pipe (Ø, mm)
9.52 mm
Liquid Pipe (Ø, inch)
3/8 inch
Gas Pipe Type
Braze Connection
Gas Pipe (Ø, mm)
15.88 mm
Gas Pipe (Ø, inch)
5/8 inch
Heat Insulation
Both liquid and gas pipes
Piping Length (ODU-IDU) Max. [Equiv.] [m]
80 [100] m
Piping Length (1st Branch-IDU) Max. [m]
40 m
Total Piping Length (System) Max. [m]
150 m
Level Difference (ODU in highest position) Max. [m]
30 m
Level Difference (IDU in highest position) Max. [m]
25 m
Level Difference (IDU-IDU) Max. [m]
15 m
Installation Max. Length [m]
80 m
Installation Max. Height [m]
30/25 m
Refrigerant
Refrigerant
refrigerant
Type
R32(Contains fluorinated greenhouse gases, GWP=675)
Factory Charging (kg)
2.20 kg
Factory Charging (tCO2e)
-
Sound
Sound
sound
Sound Pressure Level (Cooling)
55 dBA
Sound Pressure Level (Heating)
57 dBA
Sound Power Level
68/72 dBA
External Dimension (Outdoor Unit)
External Dimension (Outdoor Unit)
external_dimension_outdoor_unit
Net Weight (kg)
93 kg
Shipping Weight (kg)
103 kg
Net Dimensions (WxHxD) (mm)
940*840*460 mm
Shipping Dimensions (WxHxD) (mm)
1020*1030*575 mm
Operating Temp. Range
Operating Temp. Range
operating_temp_range
Cooling (°C)
-5 ~ 48 ℃
Heating (°C)
-25 ~ 26 ℃
Field Wiring
Field Wiring
field_wiring
Transmission Cable
0.75 ㎟
