    Capacity:2.0kW

    Heating:

    A+++_D_A++

    Cooling:

    A+++_D_A+++

    WindFree™ Avant S2 Black

    AR70F07C1ABNEU

    Request a quote

    Documentation

    Declaration of Conformity

    Download

    Climate comfort in a single space

    A single split air conditioner connects one outdoor unit to one indoor unit, for targeted and effective cooling or heating of single rooms or one-zone areas in the home. It is an ideal solution for creating climate comfort in a specific space, for instance a bedroom or home office. Our wide range of outdoor and indoor units enables you to create the perfect combination for specific needs.

    Find an installer
    Stylish baby room with toys, wooden bed and mock up poster frame. Cute home decor. Scandinavian interior of a children's room.

    Maximal comfort

    No image added
    No image added

    No cold drafts

    WindFree™ Cooling mode helps to cool wider and larger areas evenly and comfortably. It disperses the air through 23,000 micro-holes, cooling gently and quietly² and preventing cold drafts. This results in a ‘Still Air’ environment with a low air speed and limited noise¹.

    No image added
    No image added

    Fast Cooling

    Samsung wall-mounted air conditioners with WindFree™ technology cools quickly from corner to corner, making people comfortable whenever they want and wherever they are. Powerboost with Digital Inverter technology dramatically shortens the time it takes for the compressor to reach maximum power when it starts operating, so it cools the air 43% faster¹⁰. Its advanced design also features a 15% larger fan, 18% wider inlet and a 31% wider blade compared to Samsung conventional model¹¹. This means that cool air is dispersed farther and wider into every corner of a room, reaching up to 15m¹².

    No image added
    No image added

    Tri-Care Filter

    The Tri-Care Filter keeps the air cleaner and sustains the performance of the Heat Exchanger. Its three layers include a high-density filter that extracts large household dust particles, fibres and animal hair. It also has a filter with Zeolite coating that captures fine dust, and helps to reduce certain types of viruses, bacteria and allergens in the air⁴.

    No image added
    No image added

    Stylish solution

    The Samsung WindFree™ Avant S2 Black addresses the growing demand for stylish home appliances that complement modern living spaces. With smart climate control and enhanced indoor air quality, it seamlessly combines functionality with elegance to elevate comfort in the home.

    Learn more

    No image added
    No image added

    Smart Control

    Control the temperature at home, anytime and anywhere. The SmartThings App⁵ enables users to remotely control their air conditioner. With just the touch of a button, users can turn the air conditioner on or off, select the cooling mode, schedule the air conditioner’s operation and monitor its power consumption.

    No image added
    No image added

    SolarCell Remote Controller

    Samsung introduces the SolarCell Remote controller to its residential air conditioning line-up⁹ The new SolarCell remote controller focuses on innovative charging, slim design and easy usability features. The SolarCell remote controller does not need batteries; instead a solar panel is integrated on the back of the remote controller that allows charging by exposing it under direct light.

    A single, fully charged battery can last up to two years, making it an economical alternative to disposable batteries. In addition, there is also a USB-C port on the bottom of the remote control for fast charging.

    Product Comparison

    WindFree Elite S2
    WindFree Avant (Black) S2

    Specifications

    Energy Label (SEER/SCOP)
    		A+++ - A+++A+++ - A++
    refrigerant fluid
    		R32R32
    Capacity Cold (kw)
    Cooling (Nominal)
    		2.5 - 3.52 - 2.5 - 3.5 - 4.3 - 5 - 6.5
    Capacity Warm (kw)
    Heating at +7 C
    		3.2 - 4.02.2 - 3.2 - 4.0 - 4.7 - 6 -7.4
    Dimensions
    Indoor Unit (W x H x D)
    		889 x 299 x 215889 x 299 x 215 or 1.055 x 299 x 215 (above 5kw)
    Weight (Kg)
    Indoor Unit
    		10.59.9 or 12.3 (above 5kw)

    Product Specifications

    • Capacity

      Capacity

      capacity

      • Capacity (Cooling, Btu/hr)

        6824 Btu/hr

      • Capacity (Heating, Btu/hr)

        7507 Btu/hr

      • Capacity (Cooling, Min - Max, Btu/hr)

        3276 - 10919 Btu/hr

      • Capacity (Heating, Min - Max, Btu/hr)

        2388 - 22861 Btu/hr

      • Capacity (Cooling, kW)

        2.00 kW

      • Capacity (Heating, kW)

        2.20 kW

      • Capacity (Cooling, Min - Max, kW)

        0.96 - 3.2 kW

      • Capacity (Heating, Min - Max, kW)

        0.7 - 6.7 kW

    • Energy Efficiency

      Energy Efficiency

      energy_efficiency

      • SEER(W/W, Energy Label)

        9.00

      • EER (Cooling) [W/W]

        4.65 W/W

      • COP (Heating) [W/W]

        4.78 W/W

      • EER (Cooling, Btu/hW)

        15.87 Btu/hW

      • COP (Heating, Btu/hW)

        16.32 Btu/hW

      • Energy Efficiency Class for cooling (Grade) (A+++ - D)

        A+++

      • Energy Efficiency Class for heating in 'Average' heating season (Grade) (A+++ - D)

        A++

      • Energy Efficiency Class for heating in 'Average' heating season (W/W)

        4.80

    • Noise Level

      Noise Level

      noise_level

      • Sound Power Level(Indoor, Cooling, dBA)

        56 dBA

      • Sound Power Level(Outdoor, Cooling, dBA)

        59 dBA

      • Noise Level (Indoor, High/Low, dBA)

        37 / 16 dBA

      • Noise Level (Outdoor, High/Low, dBA)

        45 dBA

    • Electrical Data

      Electrical Data

      electrical_data

      • Power Source(Ø//V/Hz)

        1 / 220-240 / 50

      • Power Consumption(Cooling, W)

        430 W

      • Power Consumption(Heating, W)

        460 W

      • Operating Current(Cooling, A)

        2.3 A

      • Operating Current(Heating, A)

        2.3 A

    • Physical specification

      Physical specification

      physical_specification

      • Gross Dimension (Indoor, WxHxD, mm*mm*mm)

        950*290*375 mm

      • Gross Dimension (Outdoor, WxHxD, mm*mm*mm)

        913*622*371 mm

      • Net Dimension (Indoor, WxHxD, mm*mm*mm)

        889*299*215 mm

      • Net Dimension (Outdoor, WxHxD, mm*mm*mm)

        790*548*285 mm

      • Gross Weight (Indoor, kg)

        11.6 kg

      • Gross Weight (Outdoor, kg)

        33.0 kg

      • Net Weight (Indoor, kg)

        9.9 kg

      • Net Weight (Outdoor, kg)

        30.7 kg

      • Loading Quantity (20/40/40Hft without Pipe)

        85 / 180 / 208

    • Technical Information

      Technical Information

      technical_information

      • Piping Length (Max, m)

        20 m

      • Piping Height (Max, m)

        10 m

      • SVC Valve (Liquid (ODxL))

        6.35

      • SVC Valve (Gas (ODxL))

        9.52

      • Moisture Removal (l/hr)

        0.7 l/hr

      • Air Circulation (Cooling, m3/min)

        8.5 ㎥/min

      • Refrigerant (Type)

        R32(Contains fluorinated greenhouse gases, GWP=675)

      • Refrigerant (Charging, kg)

        0.95 kg

      • Refrigerant (Charging, tCO2e)

        0.64 tCO2e

      • Low Ambient (Cooling, °C)

        -10~46 ℃

      • Low Ambient (Heating, °C)

        -15~24 ℃

      • Outdoor Unit (Compressor Type)

        BLDC

      • Outdoor Unit (Anti-Corrosion Fin)

        Yes

    • Air Flow

      Air Flow

      air_flow

      • WindFree Cooling

        Yes

      • Air Direction Control (Up/Down)

        Auto

      • Air Direction Control (Left/Right)

        Auto

      • Air Flow Control Step (Cool/Fan)

        5/4

    • Air Purification

      Air Purification

      air_purification

      • PM 1.0 Filter

        No

      • Tri Care Filter

        Yes

      • 4-in-1 Care Filter

        No

      • Copper Anti-bacterial Filter

        No

      • Auto Clean (Self Cleaning)

        Yes

    • Convenience

      Convenience

      convenience

      • SmartThings

        Yes

      • AI Auto Cooling

        Yes

      • Motion Detect Sensor

        No

      • Freeze Wash

        Yes

      • Filter Cleaning Indicatior

        Yes

      • Indoor Temp. Display

        Yes

      • Display On/Off

        Yes

      • Beep On/Off

        Yes

      • 24-Hour Timer

        Yes

      • Auto Changeover

        Yes

      • Auto Restart

        Yes

    • Operating Mode

      Operating Mode

      operating_mode

      • Auto Mode

        Yes

      • Fast Cool

        Yes

      • Dry Comfort

        Yes

      • Good Sleep

        Yes

      • Eco Mode

        Yes

      • Dehumidification

        Yes

      • Fan Mode

        Yes

      • Quiet

        Yes

    • Smart

      Smart

      smart

      • WiFi Embedded

        Yes

    • App Connectivity

      App Connectivity

      app_connectivity

      • SmartThings App Support

        Yes

    Disclaimers

    1. ASHRAE (the American Society of Heating, Refrigerating, and Air-Conditioning Engineers) defines “Still Air” as air currents moving at speeds below 0.15 m/s, with no cold drafts.

    2. Tested on the AR12TXCAAWKNEU model in an anechoic environment. WindFree™ mode generates 23 dB(A) of noise, compared to 26 dB(A) produced by the conventional Samsung model. Sound pressure level is a relative value, depending on the distance and acoustic environment. Sound pressure level may differ according to operating conditions.

    3. Only applicable for WindFreeTM Elite S2 and WindFreeTM Avant S2

    4. Verified by Intertek testing samples of Samsung AR9500T in a continuous airflow condition (to KS K 0693:2016 protocol using bacteriophage MS2 virus ATCC 15597-B1 and Escherichiacoli strain C3000 ATCC 15597) and antiviral Tri-Care Filter (to Samsung-defined test criteria using Staphylococcus aureus ATCC 6538 and Klebsiella pneumoniae ATCC 4352).

    5. A Wi-Fi connection and Samsung SmartThings application account are required. Requires iOS 10.0 or later & Android 5.0 or later.

    6. Compared to the conventional infrared remote controller for example, the AR-EH03.

    7. AI = Artificial Intelligence. A Wi-Fi connection and Samsung SmartThings application account are required.

    8. Bixby is Samsung’s voice interface assistant. A Wi-Fi connection and a Samsung account is required. Currently Voice control is supported in English (US, UK, Indian), Chinese, Korean, French, German, Italian, Spanish, and Portuguese. Google Assistant (Google Home). Google Assistant is not available in certain languages and countries. Google is a trademark of Google LLC.

    9. The SolarCell Remote Controller is included with the WindFree™ Elite and WindFree™ S2 models and Cebu S2.

    10. Tested on the AR12TXCAAWKEU model compared with the Samsung conventional model AQ12EASER under specific testing conditions and may vary depending on environmental factors and use.

    11. Comparing the AR12TXCAAWKEU model with the Samsung conventional model AQ12EASER

    12. Tested on the AR24TXFCAWKNEU model under specific testing conditions and may vary depending on environmental factors and use.
